SiBE37-704_A Test Operation
Test Operation 166
3. Make sure to tighten the cap securely. Refer to the table below.
Closing stop valve (See figure 19)
1. Remove the cap and turn the valve clockwise with the hexagon wrench.
2. Securely tighten the valve until the shaft contacts the main body seal.
3. Make sure to tighten the cap securely.
For the tightening torque, refer to the table above.
1.2.5.4 How to check how many units are connected
It is possible to find out how many indoor units are active and connected by operating the push-
button switch on the printed circuit board (A1P) of the working outdoor unit.
Make sure that all the indoor units connected to the outdoor unit are active.
Follow the 5-step procedure as explained below.
The LEDs on the A1P shows the operating status of the outdoor unit and the number of
indoor units that are active.
The number of units that are active can be read from the LED display in the "Monitor Mode"
procedure below.
Example: in the following procedure there are 22 units active:
Note: Wherever during this procedure, press the BS1 MODE button if something becomes unclear.
You will return to setting mode 1 (H1P=
h
"OFF").
Press the BS1 MODE button to switch from setting mode 1 to monitor mode.
To check the number of indoor units, press the BS2 SET button 5 times.
Pressing the BS3 RETURN button causes the LED display to show the data on the number
of indoor units that are connected.
Calculate the number of connected indoor units by adding the values of all (H2P~H7P) blinking
(
l
) LEDs together.
In this example: 16+4+2=22 units
Press the BS1 MODE button to return to step 1, setting mode 1 (H1P=
h
"OFF").
Stop valve size
Tightening torque N•m (Turn clockwise to close)
Shaft
Cap (valve lid) Service port
Valve body
Hexagonal
wrench
φ9.5 5.4~6.6
4mm
13.5~16.5
11.5~13.9
φ12.7 8.1~9.9 18.0~22.0
φ22.2
27.0~33.0 8 mm 22.5~27.5
φ25.4
h OFF k ON l Blinking
1 Setting mode 1 (default system status)
H1P H2P H3P H4P H5P H6P H7P
Default status (normal)
hhkhhhh
2 Monitor mode
H1P H2P H3P H4P H5P H6P H7P
Default status display
lhhhhhh
3 Monitor mode
H1P H2P H3P H4P H5P H6P H7P
Selection status of how many
connected indoor units to
display.
lhhhkhk
4 Monitor mode
H1P H2P H3P H4P H5P H6P H7P
Displaying the number of
connected indoor units
lhlhllh
32168421
