SiBE37-704_A Specifications
Specifications 46
1-2 ELECTRICAL SPECIFICATIONS FXMQ20PVE FXMQ25PVE FXMQ32PVE FXMQ40PVE FXMQ50PVE
Power
Supply
Name VE
Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps
(MCA)
A 0.6 0.6 0.6 1.4 1.6
Maximum fuse amps
(MFA)
A16
Full load amps (FLA) A 0.5 0.5 0.5 1.1 1.3
Voltage
range
Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA is smaller than or equal to 4 x FLA
Next lower standard fuse rating minimum 16A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
1-2 ELECTRICAL SPECIFICATIONS FXMQ63PVE FXMQ80PVE FXMQ100PVE FXMQ125PVE FXMQ140PVE
Power
Supply
Name VE
Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps
(MCA)
A 1.8 2.3 2.9 3.4 3.4
Maximum fuse amps
(MFA)
A16
Full load amps (FLA) A 1.4 1.8 2.3 2.7 2.7
Voltage
range
Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA is smaller than or equal to 4 x FLA
Next lower standard fuse rating minimum 16A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
