SiBE37-704_A Field Setting
Test Operation 222
3.2.2 Setting by Dip Switches
(1) Factory setting of initial PCB.
Do not make any changes in all factory settings of the DIP switches on the control PCB.
* For detail of the setting procedure, refer to information on the following pages.
While the PCB assembly is replaced, the "U3" malfunction (Test run not carried out yet)
code is displayed. In this case, carry out the test run again.
If the "PJ", "UA", or "U7" malfunction code is displayed, recheck for DIP switch settings.
After the completion of rechecking for the settings, turn ON the power supply again.
Status of DIP switches
:Represents the factory setting positions
of the switches.
ON
OFF
ON
OFF
12 34
DS1
1234
DS2
Setting at replacement by spare PCB
Caution
DIP switch Setting after changing the main PCB (A1P) to spare parts PCB
After the replacement by the spare PCB, be sure to make settings shown below.
When you change the main PCB (A1P) to spare parts PCB, please carry out the following
setting.
DIP Switch Detail
DS No. Item Contents
DS1-2 Power supply
specification
ON 200V class (220V)
OFF
(Factory
setting of spare
PCB)
400V class (380V)
DS1-3
Except
Multiple
use
Cooling only/Heat-
pump setting
ON Cooling only setting
OFF
(Factory
setting of spare
PCB)
Heat pump setting
DS1-4 Unit allocation
setting
ON
Make the following settings according to allocation of
unit. (All models are set to OFF at factory.)
DS2-1
OFF (Factory
setting of spare
PCB)
DS2-2 Model setting
Make the following settings according to models of outdoor units.
(All models are set to OFF at factory.)
* Refer to following pages for setting detail.
DS2-3
DS2-4
Initial conditions of dip switches
ON
OFF
1234
DS1
ON
OFF
1234
DS2
Multiple
use Single
use (Main)
Single use
(Sub)
Domestic
Japan
Overseas
General
Europe
DS1-4 DS1-3
OFF OFF ON
DS2-1 DS1-4
OFF ON OFF
