SiBE37-704_A Troubleshooting by Remote Controller
Troubleshooting 268
System U0 k Gas shortage alert 353
U1 l Reverse phase, open phase 355
U2 l Power supply insufficient or instantaneous failure 356
U3 l Check operation not executed 359
U3 k Check operation is not completed. 359
U4 l Malfunction of transmission between indoor units and outdoor units 360
U5 l Malfunction of transmission between indoor units 363
U5 h Malfunction of transmission between remote controller and indoor unit 363
U7 l Transmission failure (Across outdoor units) 364
U8 l Malfunction of transmission between main and sub remote controllers 370
U9 l Malfunction of transmission between indoor and outdoor units in the same
system
371
UA l Improper combination of indoor and outdoor units, indoor units and remote
controller
372
UC k Address duplication of centralized controller 378
UE l Malfunction of transmission between centralized controller and indoor unit 379
UF l System is not set yet 382
UH l Malfunction of system, refrigerant system address undefined 383
Centralized
Remote
Controller
and
Schedule
Timer
M1 k or h PCB defect 385
M8 k or h Malfunction of transmission between optional controllers for centralized
control
386
MA k or h Improper combination of optional controllers for centralized control 387
MC k or h Address duplication, improper setting 389
Heat
Reclaim
Ventilation
64 k Indoor unit’s air thermistor error —
65 k Outside air thermistor error —
6A k Damper system alarm —
6A l Damper system + thermistor error —
6F k Malfunction of simple remote controller —
6H k Malfunction of door switch or connector —
94 l Internal transmission error —
k: ON h: OFF l: Blink
Malfunction
code
Operation
lamp
Malfunction contents Page
Referred
The system operates for malfunction codes indicated in black squares, however, be sure to check and repair.
