Specifications SiBE37-704_A
31 Specifications
1-2 ELECTRICAL SPECIFICATIONS FXCQ20M8V3B FXCQ25M8V3B FXCQ32M8V3B FXCQ40M8V3B FXCQ50M8V3B
Power
Supply
Name V3
Phase 1 1 1 1 1
Frequency Hz 50 50 50 50 50
Voltage V 230 230 230 230 230
Current Minimum circuit amps
(MCA)
A 0.50 0.50 0.50 0.80 0.80
Maximum fuse amps
(MFA)
A 16.00 16.00 16.00 16.00 16.00
Full load amps (FLA) A 0.40 0.40 0.40 0.60 0.60
Voltage
range
Minimum V -10%
Maximum V +10%
Power Supply Intake Both indoor and outdoor unit
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA<= 4 x FLA
select wire size based on the MCA
instead of a fuse, use a circuit breaker
For more details concerning conditional connections, see http://extranet.daikineurope.com, select "E-Data Books".
Finally, click on the document title of your choice.
1-2 ELECTRICAL SPECIFICATIONS FXCQ63M8V3B FXCQ80M8V3B FXCQ125M8V3B
Power
Supply
Name V3
Phase 1 1 1
Frequency Hz 50 50 50
Voltage V 230 230 230
Current Minimum circuit amps
(MCA)
A 0.90 1.10 1.30
Maximum fuse amps
(MFA)
A 16.00 16.00 16.00
Full load amps (FLA) A 0.70 0.90 1.00
Voltage
range
Minimum V -10%
Maximum V +10%
Power Supply Intake Both indoor and outdoor unit
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA<= 4 x FLA
select wire size based on the MCA
instead of a fuse, use a circuit breaker
For more details concerning conditional connections, see http://extranet.daikineurope.com, select "E-Data Books".
Finally, click on the document title of your choice.
