Test Operation SiBE37-704_A
171 Test Operation
∗
= The state of this LED is not important.
When a malfunction occurs, check the display of the remote controller and refer to "3. Remote
controller malfunction code display" on page 172.
9. Complete
The display on the remote controller shows a flashing
PE
code for signalling that automatic
charging will be finished in about 10 minutes.
When the unit stops operating, close valve A immediately and check the LEDs and check if
the
P9
code is displayed on the remote controller.
Note: Always close valve A and remove the refrigerant tank immediately after finishing the refrigerant
charge operation.
The refrigerant charge port of these units have electric expansion valves that will close
automatically when refrigerant charging operation has finished. However, the electric expansion
valves will be opened when other operations start after finishing refrigerant charging operation.
If the refrigerant tank is left with the valve open, the amount of refrigerant which is properly
charged may be off the point.
If the LED indication is not as shown above, correct the malfunction (as indicated in the
display of the remote controller) and restart the complete charging procedure. When the
charging amount is little, the
PE
code may not be displayed, but instead the
P9
code will be
displayed immediately.
Beware of the fan blades when you open the front panel.
The fan may still rotate for a while after unit operation has stopped.
10.In case leak detection function required
Press the BS4 TEST button once for post-processing with regard to the leak detection
function and press the BS1 MODE button to confirm that charging is completed.
Record the amount that was added on the additional refrigerant charge label provided with
the unit and attach it on the back side of the front panel.
Perform the procedure " 1.2.5.6 Procedure for inputting the additional refrigerant charge
weight into the PCB" as described on page 172.
10.In case leak detection function not required
Press the BS1 MODE button once and the charging is complete.
Record the amount that was added on the additional refrigerant charge label provided with
the unit and attach it on the back side of the front panel.
Perform the procedure " 1.2.5.6 Procedure for inputting the additional refrigerant charge
weight into the PCB" as described on page 172.
H1P H2P H3P H4P H5P H6P H7P
kl ∗∗∗∗∗
H1P H2P H3P H4P H5P H6P H7P
lllkkkk
H1P H2P H3P H4P H5P H6P H7P
kllkkkk
2. Normal system display
LED display
(Default status
before delivery)
Micro-
computer
operation
monitor
Mode
Ready/
Error
Cooling/Heating
changeover
Low
noise
Demand
Indivi-
dual
Bulk
(master)
Bulk
(slave)
HAP
H1P H2P H3P H4P H5P H6P H7P
Outdoor unit
system
l hhkhhhh
