Daikin REYQ42P8Y1B [192/494] Final check after installation
![Daikin REYQ38P8Y1B [192/494] Final check after installation](/views2/1705722/page192/bgc0.png)
Test Operation SiBE37-704_A
181 Test Operation
After correcting the abnormality, press the BS3 RETURN button and reset the malfunction
code.
Carry out the test operation again and confirm that the abnormality is properly corrected.
1.2.5.8.5 Final check after installation
After all installation works are completed, operate the unit normally and check the following:
Make sure the indoor units and outdoor unit are operating normally.
Operate each indoor unit separately and make sure the corresponding outdoor unit is also
operating properly.
Check if cold or hot air is coming out from the indoor unit.
Push the fan direction and fan strength buttons on the remote controller to check if they are
operating properly.
Note:
Heating is not possible if the outdoor temperature is 24°C or higher. Refer to the operation
manual.
If a knocking sound is heard in the liquid compression of the compressor, stop the unit
immediately and then energize the crankcase heater for a sufficient length of time before
restarting the operation.
Once stopped, the compressor will not restart in about 5 minutes, even if the ON/OFF button
on the remote controller is pushed.
When the system operation is stopped by the remote controller, the outdoor unit may
continue operation for a maximum of 5 minutes.
The outdoor fan may rotate at low speeds in the night-time low noise setting or the external
low noise level setting is made; but this is not a malfunction.
1.2.5.8.6 Service mode operation
Note: Do not shut off the power and do not reset the setting of mode 2 when vacuuming or recovering
refrigerant. Otherwise the expansion valves will close making it impossible to vacuum the
system or to recover the refrigerant.
Vacuuming method
At the first installation, this vacuuming is not required. It is required only for repair purposes.
1. When the unit is at standstill and under the setting mode 2, set the required function B
(refrigerant recovery operation/vacuuming operation) to ON (ON).
- The indoor unit, BS units and the outdoor unit expansion valves will fully open.
- The H1P LED is on and the remote controller indicates TEST (test operation) and
(external control) and the operation will be prohibited.
2. Evacuate the system with a vacuum pump.
3. Press the BS1 MODE button and reset the setting mode 2.
Refrigerant recovery operation method
by a refrigerant reclaimer
1. When the unit is at standstill and under the setting mode 2, set the required function B
(refrigerant recovery operation/vacuuming operation) to ON (ON).
- The indoor unit, BS unit and the outdoor unit expansion valves will fully open.
- The H1P LED is on and the remote controller indicates TEST (test operation) and
(external control) and the operation will be prohibited.
2. Recover the refrigerant by a refrigerant reclaimer. For details, see the operation manual
delivered with the refrigerant reclaimer.
3. Press the BS1 MODE button and reset the setting mode 2.
