Icom IC-F8101 [18/88] Functions for transmit

Functions for transmit ■

Transmit power selection D

The transceiver has three output power levels, HIGH,

MID and LOW. High power provides longer distance

communications and low power reduces power con-

sumption.

[Default]

Push q [8] to enter the Main Menu screen.

Select the “RF Power” item of “Setmode.” w

q Push [r] or [s] to select the item, and then

push [4] to open the screen.

(Setmode > Conﬁg)

w Push [r] or [s] to select “RF power,” and then

hold down [4] for 1 second.

Push e [r] or [s] to select the desired option, LOW,

MID or HIGH.

• If desired, hold down [Default](§§) for 1 second to re-

turn to the default setting

Push r [4] to save the setting, and return to the pre-

vious screen.

Push t [8] one or more times to exit.

Setting Microphone gain D

The microphone gain must be properly adjusted so

that your signal is not distorted when transmitted.

[Default]

Push q [8] to enter the Main Menu screen.

Select the “Mic Gain” item of “Setmode.” w

q Push [r] or [s] to select the item, and then

push [4] to open the screen.

(Setmode > Conﬁg)

w Push [r] or [s] to select “Mic Gain,” and then

hold down [4] for 1 second.

Push e [r] or [s] to adjust the desired setting level

to between 0 and 10.

• If desired, hold down [Default](§§) for 1 second to re-

turn to the default setting

Push r [4] to save the setting, and return to the pre-

vious screen.

Push t [8] one or more times to exit.

RECEIVE AND TRANSMIT
