![Icom IC-F8101 [71/88] Quick reference](/img/pdf.png)
Icom IC-F8101 [71/88] Quick reference
![Icom IC-F8101 [71/88] Quick reference](/views2/1074229/page71/bg47.png)
2001 NEW
65
5
MENU SCREEN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Quick Reference
If you want to initialize the operating settings in the
Main Menu, without clearing memory channel con-
tents or ID contents, do the following steps.
q Turn OFF the transceiver power, if it is powered
ON.
w While holding down [r] and [s], and push [
] to
turn ON the transceiver power to reset the CPU.
/
■ CPU Reset
