CONNECTION AND INSTALLATION
2001 NEW 2001 NEW2001 NEW
■ Supplied accessories
er
y
t
u
qw
e
yt
u
qw
i
o
r
D One package type
The following accessories are supplied with IC-F8101
One package type.
q Microphone ........................................................... 1
w External speaker ................................................... 1
e DC power cable..................................................... 1
r Spare fuses (ATC 30 A) ........................................ 2
t Microphone hanger kit .................................... 1 set
y Rubber feet ........................................................... 4
u Sponge .................................................................. 1
D Separated Type
The following accessories are supplied with IC-F8101
Separated type.
q Microphone ........................................................... 1
w External speaker ................................................... 1
e DC power cable..................................................... 1
r Spare fuses (ATC 30 A) ........................................ 2
t Microphone hanger kit .................................... 1 set
y Rubber feet ........................................................... 4
u Remote controller with mounting bracket .............. 1
i Separation kit* ................................................. 1 set
o Sponge .................................................................. 1
* The separation cable is not supplied, and must be pur-
chased separately according to the cable length.
