Icom IC-F8101 [73/88] Quick reference
![Icom IC-F8101 [73/88] Quick reference](/views2/1074229/page73/bg49.png)
2001 NEW
67
6
CONNECTION AND INSTALLATION
2001 NEW
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Quick Reference
er
ut iy
qw
o
D Remote control microphone Type
The following accessories are supplied with IC-F8101
Remote control microphone type.
q Remote control microphone .................................. 1
w External speaker ................................................... 1
e DC power cable..................................................... 1
r Spare fuses (ATC 30 A) ........................................ 2
t Microphone hanger kit .................................... 1 set
y Screw .................................................................... 1
u Rubber feet ........................................................... 4
i Separation MIC connector .................................... 1
o Sponge .................................................................. 1
* The separation cable is not supplied, and must be pur-
chased separately according to the cable length.
