RECEIVE AND TRANSMIT

2001 NEW 2001 NEW

Functions for receive ■

Clariﬁer function D

The Clariﬁer function compensates for off-frequency

stations. The function shifts the receive frequency up

to ±200 Hz in 10 Hz steps, without shifting the trans-

mit frequency.

Upper shiftLower shift

Push q [CLAR](7) to open the Clariﬁer adjustment

window.

Push w [r] or [s] to adjust the frequency shift.

• The transmit frequency is not shifted.

Push e [CLAR](7) to save the setting, and return to

the previous screen.

• If desired, push [8] to cancel the setting and exit the

window .

When cancelling the Clariﬁer function, set the fre-

quency shift to 0 Hz in the Clariﬁer adjustment win-

dow.

Preamp and Attenuator D

The preamp ampliﬁes received signals in the front

end circuit to improve the S/N ratio and sensitivity.

Turn ON this function to better receive weak signals.

The attenuator prevents strong undesired signals near

the desired frequency or near your location, such as

from a broadcast station, from causing distortion or

spurious signals.

[Default]

Push q [8] to enter the Main Menu screen.

Select the “Pre Amp” item of “Setmode.” w

q Push [r] or [s] to select the item, and then

push [4] to open the screen.

(Setmode > Conﬁg)

w Push [r] or [s] to select “Pre Amp,” and then

hold down [4] for 1 second.

Push e [r] or [s] to select the desired option, ON,

OFF or ATT ON.

• If desired, hold down [Default](§§) for 1 second to re-

turn to the default setting

Push r [4] to save the setting, and return to the pre-

vious screen.

Push t [8] one or more times to exit.
