MENU SCREEN
2001 NEW 2001 NEW
Time Set mode
Local
Set the Local time.
Before programming this item, the “UTC Offset”
item must be set.
Push q [r] or [s] to select this item, and then hold
down [4] to open the programming screen.
Push w [r] or [s] to select the digit.
• Push [4] to move the cursor right, push [8] to move
the cursor left.
After the ‘second’ digit is programmed, push e [4] to
set the time and return to the previous screen.
UTC Offset
Select the time difference between UTC (Universal
Time Coordinated) and the local time.
–12.0 to + 12.0 (in 0.5* steps)
* 0.5 = 30 minutes
This item must be set before programming the “Lo-
cal” item.
Setmode D (Continued)
