For FHY71F Si-71A
148 Removal Procedure
2.5 Removal of Fan Bearing
Procedure
Warning Be sure to turn off all power supplies before disassembling work.
Step Procedure Points
∗
Remove the fan rotor according to
the procedures for removing the fan
rotor and fan motor.
1 Remove the left side panel
installation screw.
2 Slide the left side panel
toward the front of the unit
and remove.
3 Remove the 2 bearing
installation screws and
remove the bearing.
