Electric Function Parts Si-71A
60 Explanation of Function Operation
R
∗
Figures inside parentheses are for E unit (anti-corrosion specifications).
R71KVAL R100KVAL R125KTAL
M1C Compressor JT85BC-VH JT118-VH JT150BC
J1HC Crank Case Heater 33W
S1PH Pressure Switch for Maintaining
High Pressure
ACB-DB82
OFF : 30
+0
-1
(kg/cm²G)
ON : 22
±
1.5 (kg/cm²G)
S1LP Pressure Switch for Low
Pressure Control
20PS-1164-1
OFF : –23
±
15 (cmHg)
ON : 0.5
±
0.3 (kg/cm²G)
K1M Magnetic Switch HOE-26F-TRA1
F1C Overcurrent Relay 22A 26A 22A
M1F Outdoor Unit Fan (Upper) 75W 85W
M2F Outdoor Unit Fan (Lower) — 80W
Q1L
Q2L
Outdoor Unit Fan Motor Safety
Thermostat
OFF : 135
±
5°C
ON : Below 120°C
C1R Capacitor for M1F 6
µ
F
C2R Capacitor for M2F — 6
µ
F
A1P Outdoor Unit Control PC Board
∗
EC9523 EC9527 EC9528
A2P Outdoor Control PC Board
(Models for the FJ Type Only)
—
R1T Thermistor (for Outdoor Air) ST9303
R2T Thermistor (for Heat Exchanger) ST8604A ST9604A ST8604A
R3T Thermistor (for Discharge Pipe) ST8606
T1R Transformer TR21H16R2
Y1E Electronic Expansion Valve DKV18D93 (Main Unit) EKV24D34 (Main Unit) EKV26D35
DKV-MOZS130B0 (Coil) EKV-MOZS107B0 (Coil)
K1S Starting Relay CLK-15J02-P15 CLK-15J02-P14 —
C3R,
C4R
M1C Capacitor 46
µ
F+23
µ
F—
C5R Starting Capacitor 50
µ
F+50
µ
F75
µ
F+75
µ
F—
