Si-71A Method of Field Set (Reset after Maintenance Inspection/Repair)
Explanation of Field Set 23
Caution
When “auto restart after power outage reset” is set, be sure to turn off air conditioners, then cut off the
power supply before conducting maintenance, inspection and other work. If the power supply is cut off with
the power switch left ON, air conditioners will automatically start operating when the power supply is turned
on.
7. Do not set any items other than those listed in the above table.
8. Functions that indoor units are not equipped with will not be displayed.
9. When returning to normal mode, “88” may be displayed on the LCD section of the remote controller due
to initialization operation.
