Daikin FHK35FJV1 [37/244] Explanation of field set

Method of Field Set (Reset after Maintenance Inspection/Repair) Si-71A

26 Explanation of Field Set

After completing setting, seal off the opening of the address switch and the MAIN/SUB switch with the

attached sealing pad.

Setting The

Address of

Wireless Remote

Controller

(It is Factory Set to

“1”)

1. Hold down the “ “ button and the “ “ button for at least 4 seconds, to get the

FIELD SET MODE. (Indicated in the display area in the figure at right).

2. Press the “ “ button and select a multiple setting (A/b). Each time the button is pressed the

display swicthes between “A” and “b”.

3. Press the “ “ button and “ “ button to set the address.

Address can be set from 1 to 6, but set it to 1 ~ 3 and to same address as the receiver. (The receiver

does not work with address 4 ~ 6.)

4. Press the “ “ button to enter the setting.

5. Hold down the “ “ button for at least 1 second to quit the FIELD SET MODE and return to

the normal display.
