Si-71A Electric Function Parts
Explanation of Function Operation 53
3. Electric Function Parts
3.1 Indoor Unit
FH(Y)C~KVE, KV1C
FH(Y)K~F(J)
FH(Y)B~F
FH(Y)~F
Drawing No. given inside brackets[ ].
Capacity 35 50 60 71 100 125 140 Remarks
Wired Remote Controller BRC1B51·61 (C) (EC9505) Optional
Accessory
Wireless Remote
Controller
HEAT PUMP USE : BRC7C612W (C)
COOLING ONLY USE : BRC7C613W (C)
Optional
Accessory
Electronic Control Unit FHYC : EC9743 FHC : EC9744
Fan Motor (Temperature
Protector 130°C)
KFP-220-45B
6P 45W
D17P90H23
6P 90W
Fan Motor Capacitor 3.5
µ
F5
µ
F
Swing Flap Motor
(with Limit Switch)
MP35HCA (3P007482-1)
Float Switch FS-0211B
Drain Pump PLD-12230DM-1
Capacity 35 45 60 71 Remarks
Wired Remote Controller BRC1B51·61 (EC9505) Optional
Accessory
Electronic Control Unit FHYK, FHK71:EC9516 FHK35~60:EC9521
Fan Motor (Temperature
Protector 120°C)
BP-NRTW
4P 20W
BP-NRTW
4P 25W
BP-NRTW
4P 45W
Fan Motor Capacitor 2
µ
F2.5
µ
F
Swing Flap Motor
(with Limit Switch)
MT8-L [3PA07312-1]
Float Switch FS-0406C
Drain Pump CJV-0927
Capacity 35 45 60 71 100 125 Remarks
Wired Remote Controller BRC1B52·62 (EC9505) Optional
Accessory
Electronic Control Unit FHYB:EC9514 FHB:EC9520 EC9515
Fan Motor (Temperature
Protector 152°C)
CA-
0513D
4P 65W
CA-
0514D
4P 85W
CA-
0516D
4P 110W
V1:CA-
0515D
4P 125W
VAL:CA-
4526D
4P 125W
A37P135
G20
4P 135W
A37P225
C20
4P 225W
Fan Motor Capacitor 4
µ
F5
µ
F5
µ
FV1:3
µ
F
VAL:5
µ
F
V1:5
µ
F
VAL:10
µ
F
Float Switch FS-0406D
Drain Pump CJV-0929
Capacity 35 45 60 71 100 125 Remarks
Wired Remote Controller BRC1B51·52·61·62 (EC9505) Optional
Accessory
Electronic Control Unit FHY~FJV1:EC9513 FHY~FVE:EC9543
FH~FJV1/FVE:EC9519 FH~FJV1/FVE:EC9522
Fan Motor (Temperature
Protector 130°C)
D09P57A23A
4P 57W
D10P/30E23A
4P 130W
Fan Motor Capacitor 2
µ
F3
µ
F6
µ
F
Swing Flap Motor FHY~F(J):MTL8-L [3PA07121-1]
