Method of Field Set (Reset after Maintenance Inspection/Repair) Si-71A

22 Explanation of Field Set

1.4 Local Setting Mode No.

Example

To set the filter sign time to “filter contamination - heavy” for all units in a group:

Set mode No. to “10,” setting switch No. to “0,” and setting position No. to “02.”

Table

Notes:

1. Setting is made in all units in a group. To set for individual indoor units or to check the setting, use the

mode Nos. (with “2” in upper digit) in parentheses ( ).

2. The setting position No. is set to “01” at the factory, except for the following cases in which “02” is set.

„

Setting of air flow direction adjustment range

„

Automatic restart after power outage.

„

Remote control thermostat

„

Filter sign indication (only for ceiling-mounted duct type)

3. When installing Sky Air simultaneous operation multi-unit, set to either “twin” or “triple.”

Only when the factory setting is changed, it is necessary to make a setting using a remote controller.

4. For further details, see the installation instruction.

5. Since drafts may result, carefully select the installation location.

6. When power returns, units resume the settings made before the power outage.

Mode

No.

Note 1

Setting

Switch

No.

Setting Description Setting Position No. *Note 2

01 02 03

10(20) 0 Filter contamination - heavy / light

(Setting of operating hours for filter

sign indication) (Change setting

when reducing filter sign indication

time to half due to quick soiling of

filter)

Urtra-Long-

Life Type

Light Approx.

10,000

hours

Heavy Approx.

5,000

hours

—

Long-Life

Type

Approx.

2,500

hours

Approx.

1,250

hours

Standard

Type

Approx.

200 hours

Approx.

100 hours

1 Long-life filter type (Setting of filter sign indication

time)

(Change setting when Urtra-long-life filter is

installed)

Long-Life Filter Urtra-Long-Life Filter

(1)

Setting Description

Urtra-Long-Life Filter

(2)

3 Estimation of filter operating hour

(Change setting when filter sign indication is not

used)

ON OFF —

11(21) 0 No. of Sky Air indoor units connected for

simultaneous ON-OFF multi system

(Change setting when simultaneous operation

multi system is used) *Note 3

Pair Twin Triple

1 Simultaneous operation multi-unit individual

setting

Unified Individual —

2 Indoor unit fan OFF when cooling/heating is OFF — Fan OFF —

12(22) 3 Change to set fan speed when heater thermostat

is OFF *Note 5

Fan Speed LL Set Fan Speed —

5 Automatic restart after power outage reset

*Note 6

OFF ON —

13(23) 0 High

Ceiling

Ceiling-mounted built-in multi-flow

cassette type, Ceiling suspended

cassette type

NHS

Ceiling-suspended type, wall-mounted

typ

2.7 m or Lower 2.7~3.5 m —

Fan speed increase (wall-mounted type) Standard Slight Increase Normal Increase

1 Air flow direction selection (Change setting when

blocking kit is installed) *Note 4

FTW

3 Air flow direction adjustment (Change setting

when decorative air outlet panel is installed)

Installed Not Installed —

4 Setting of air flow direction adjustment range Upward Standard Downward

5 On-site fan speed change by air outlet (When

using phase control)

Standard Option 1 Option 2

6 External static pressure setting (To be set

according to connected duct resistance) (High

ceiling setting in the case of FHYK)

Standard (Standard) High Static Pressure

(High Ceiling Setting)

Low Static Pressure
