5-36
Chapter 5: BIOS Setup
Gear Down Mode [Auto]
This option allows you to select the Gear Down Mode.
Configuration options: [Disabled] [Enabled] [Auto]
CAD Bus Configuration
CAD Bus Timing User Controls [Auto]
This option allows you to set the setup time on CAD bus signals to Auto or manual.
Configuration options: [Manual] [Auto]
CAD Bus Drive Strength User Controls [Auto]
This option allows you to set the Drive Strength on CAD bus signals to Auto or manual.
Configuration options: [Manual] [Auto]
Data Bus Configuration
Data Bus Configuration User Controls [Auto]
This option allows you to interleave memory blocks across DRAM chip selects for
node 0.
Configuration options: [Auto] [Manual]
The following item appears only when
Data Bus Configuration User Controls
is set to
[Manual]
.
RttNom [Auto]
Configuration options: [Rtt_Nom Disable] [RZQ/4] [RZQ/2] [RZQ/6] [RZQ/1]
[RZQ/5] [RZQ/3] [RZQ/7] [Auto]
RttWr [Auto]
Configuration options: [Dynamic ODT Off] [RZQ/2] [RZQ/1] [Hi-Z]
[RZQ/3] [Auto]
RttPark [Auto]
Configuration options: [Rtt_PARK Disable] [RZQ/4] [RZQ/2] [RZQ/6] [RZQ/1]
[RZQ/5] [RZQ/3] [RZQ/7] [Auto]
Common RAS
Data Poisoning [Auto]
This option allows you to enable or disable Data Poisoning.
Configuration options: [Disabled] [Enabled] [Auto]
DRAM Post Package Repair [Disabled]
Configuration options: [Disabled] [Enabled]
RCD Parity [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
DRAM Address Command Parity Retry [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
