Asus RS500A-E10-RS4 [16/150] Chapter 1 product introduction

Chapter 1: Product Introduction

1-6

Model Name

RS500A-E10-PS4 RS500A-E10-RS4 RS500A-E10-RS12U

Power Supply

(following different

configuration by region)

Single 650W 80 PLUS

Platinum Power Supply

Rating:

100~127/200~240Vac,

9A/5A, 50~60Hz, Class I

1+1 Redundant 650W 80 PLUS Platinum

Power Supply

Rating: 100~127/200~240Vac, 7.8A/3.8A (for

each inlet), 50~60Hz or 240Vdc, 4.6A

Environment

Operating temperature: 10

C – 35

Non operating temperature: -40

C – 70

Non operating humidity: 20% – 90% (Non condensing)

*Specifications are subject to change without notice.
