ASUS RS500A-E10 Series
1-5
Model Name
RS500A-E10-PS4 RS500A-E10-RS4 RS500A-E10-RS12U
Auxiliary Storage Device
Bay (Optical Drive)
1 x Slim-type Optical Drive N/A
Front I/O Ports
2 x USB 3.0 ports
1 x VGA port
N/A
Rear I/O Ports
2 x USB 3.0 ports
1 x VGA port
2 x RJ-45 1GbE LAN ports
1 x RJ-45 Management port
1 x COM port
Switch/LED
Rear:
- 1 x Power Switch/LED
- 1 x Q-Code/Port 80 LED
- 1 x Location LED
Front:
- 1 x Power Switch/LED
- 1 x Location Switch/LED
- 1 x Reset Switch
- 1 x Message LED
- 4 x LAN LED (LED1~2 for on-board LAN,
3~4 for OCP LAN)
Rear:
- 1 x Power Switch/LED
- 1 x Q-Code/Port 80 LED
- 1 x Location LED
Front:
- 1 x Power Switch/LED
- 1 x Message LED
- 4 x LAN LED (LED1~2
for on-board LAN,
3~4 for OCP LAN)
- 1 x Location LED
OS Support
Please find the latest OS support from http://www.asus.com/
Management
Solution
Software
ASUS Control Center
Out of Band
Remote
Management
On-Board ASMB9-iKVM for KVM-over-IP
Regulatory Compliance
BSMI, CE, FCC
Dimension (HH x WW x
DD)
615 x 444 x 44mm (1U)
24.21” x 17.48” x 1.73”
Net Weight Kg (CPU,
DRAM & Storage device
not included)
10 Kg 11 Kg 11.5 Kg
Gross Weight Kg (CPU,
DRAM & Storage device
not included, Packing
included)
16 Kg 17 Kg 17.5 Kg
(continued on the next page)
