5-39
ASUS RS500A-E10 Series
Package Power Limit Control [Manual]
Configuration options: [Disabled] [Enabled] [Auto]
The following item appears only when
cTDP Control
is set to
[Manual]
.
Package Power Limit [240]
This option allows you to set the cTDP value.
APBDIS [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
DF Cstates [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
CPPC [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
BoostFmaxEn [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
NBIO RAS Common Options
Determinism Control [Auto]
Configuration options: [Manual] [Auto]
NBIO RAS Global Control [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
NBIO RAS Control [MCA]
Configuration options: [MCA] [Legacy] [Disabled]
Egress Poison Severity High
This option allows you to set the Egress Poison Severity High value.
Egress Poison Severity Low
This option allows you to set the Egress Poison Severity Low value.
NBIO SyncFlood Generation [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
NBIO SyncFlood Reporting [Disabled]
Configuration options: [Disabled] [Enabled]
Egress Poison Mask High
This option allows you to set the Egress Poison Mask High value.
Egress Poison Mask Low
This option allows you to set the Egress Poison Mask Low value.
Uncorrected Converted to Poison Enable Mask High
This option allows you to set the Uncorrected Converted to Poison Enable Mask High
value.
Uncorrected Converted to Poison Enable Mask Low
This option allows you to set the Uncorrected Converted to Poison Enable Mask Low
value.
