Asus RS500A-E10-RS4 [97/150] The utility verifies the file then starts updating the bios file

5-5

ASUS RS500A-E10 Series

4. The utility verifies the file, then starts updating the BIOS file.

DO NOT shut down or reset the system while updating the BIOS to prevent system boot

failure!

5. The utility returns to the DOS prompt after the BIOS update process is completed.

Reboot the system from the hard disk drive.

The BIOS update is finished! Please restart your system.

C:\>

Current Platform

Platform : KRPA-U16

Version : 0201

Build date: 12/04/2018

New Platform

Platform : KRPA-U16

Version : 0207

Build date: 01/05/2019

ASUS Tek. EzFlash Utility

Start Programming Flash. DO NOT SHUTDOWN THE SYSTEM!!!

Write

75%
