5-41
ASUS RS500A-E10 Series
5.11.5 FCH Common Options
USB Configuration Options
XHCI Controller0 enable [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
XHCI Controller1 enable [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
USB ecc SMI Enable [Auto]
Configuration options: [Off] [Enabled] [Auto]
MCM USB
XHCI2 enable (Socket1) [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
XHCI3 enable (Socket1) [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
