Руководство пользователя Страница: 60

Asus RS500A-E10-RS4 [60/150] Rs500a e10 rs12u

Chapter 2: Hardware Information

2-34

Connects to NVMe/SAS/SATA

storage devices

Connects to NVMe/SAS/SATA

storage devices

Connects to NVMe/SAS/SATA

storage devices

Connects to the motherboardConnects to the motherboard

Connects to the ASUS PCIE-NVME2-OCuLink

card for Bay 9 to Bay 12

Connects to the motherboardConnects to the motherboard

Connects to the motherboard

Connects to 8-pin plug

from power board

Connects to 4-pin plug

from power board

RS500A-E10-RS12U

Connects to the ASUS PCIE-NVME4-

OCuLink card for Bay 5 to Bay 8
