Asus RS500A-E10-RS4 [13/150] Serial number label

Asus RS500A-E10-RS12U [13/150] Serial number label

ASUS RS500A-E10 Series

1-3

1.2 Serial number label

Before requesting support from the ASUS Technical Support team, you must take note of the

product’s serial number containing 12 characters such as xxS0xxxxxxxx shown as the figure

below. With the correct serial number of the product, ASUS Technical Support team members

can then offer a quicker and satisfying solution to your problems.

4 3 2 1

xxS0xxxxxxxx

RS500A-E10 Series

xxS0xxxxxxxx

RS500A-E10 Series
