4 Summary of menu options
Below you will find a summary of the
menu options, which are used to
change and save the appliance's fac-
tory settings, as well as to start pro-
grammes and look up information. You
will find detailed information about
this in the subsequent chapters of this
instruction manual.
•«CHOOSE LANGUAGE» menu
Display language - there is a choice of
several languages.
•«WATER HARDNESS» menu
Programmable level of hardness bet-
ween 1 (soft) and 4 (very hard).
Factory setting: 4 (very hard).
•«TEMPERATURE» menu
Programmable coffee temperature bet-
weenLOW, MEDIUM and HIGH.
Factory setting: HIGH
•«AUTO SHUTOFF TIME» menu
Programmable switch-off time bet-
ween 1 hour and 3 hours.
Factory setting: 1h (1 hour).
•«JUG PROGRAM» menu
Programmable filling quantity (cup
size) and amount of ground coffee
(coffee strength) for cups being made
in the jug.
•«COFFEE PROGRAM» menu
Adjust filling quantity for any cup size
(espresso cup, small cup, medium cup,
large cup, mug).
•«CAPPUCCINO PROGRAM»
menu
Adjust quantity of milk or coffee for
cappuccino.
•«HOT WATER PROGRAM»
menu
Adjust quantity of hot water.
•«DESCALE» menu
Start the descaling procedure.
•«STATISTICS» menu
Look up number of cups of coffee
made, number of jugs with 4, 6, 8 or 10
cups or number of descaling proce-
dures carried out.
•«RESET TO DEFAULT» menu
Reset the changed appliance settings
to factory settings.
5 Menu mode
Pressing the "MENU" button (Figure 5)
switches to menu mode. In menu
mode, the buttons"1 cup of coffee"
, "2 cups of coffee“" , "hot
water" and "MENU" are used to nav-
igate. The respective function is shown
above the button in the display
(Figure 6):
•«<» ("1 cup of coffee" ) and
«>» ("2 cups of coffee" ) allow you
to "scroll" in the menu
•«OK» ("hot water" ) confirms a menu
option
•«ESC» ("MENU") returns to the last
menu level without making any
changes
6 Using for the first time
6.1 Setting up appliance and
connecting it
Choose a suitable surface that is hori-
zontal, stable, unheated, dry and
waterproof.
1
Make sure that air can circulate well.
There must be a gap of at least 5 cm at
each side and behind the appliance,
and at least 20 cm above the appli-
ance.
The appliance must not be installed in
areas where temperatures of 0°C and
below can arise (damage to appliance
due to freezing water).
1
Warning! If the appliance is installed in
a warm area after coming out of the
cold, wait approx. 2 hours before
switching on!
We recommend laying a suitable base
under the appliance to prevent damage
from splashes.
0 Only connect the appliance to an
earthed socket. Do not use an
unearthed socket.
