g
119
is filled with about 30 ml of water, the
progress bar is completed.
The appliance now displays
«TURNING OFF
PLEASE WAIT...» and switches
itself off.
0 To fill the coffee bean container with
coffee beans, see „Filling the coffee
bean container“ page 118.
1
Warning! To prevent malfunctions,
never fill with ground coffee, frozen or
caramelised coffee beans or anything
else that could damage the appliance.
0 Press the "On/Off" button on the
control panel (Figure 11).
The appliance displays «HEATING
UP...» on the top line of the display
and on the bottom line a progress bar
with a percentage
«
 40%»
which shows the heating up progress.
When the appliance has finished heat-
ing up it displays:
«RINSING...» on the top line of the
display and in the bottom line a
progress bar with a percentage
«
 40%» and
does an automatic rinsing process (A
little hot water comes out of the cof-
fee dispenser and is caught in the drip
tray).
The appliance now displays the basic
settings, i.e. the cup size on the top line
of the display and the coffee strength
on the bottom line, e.g.:
«MEDIUM CUP
NORMAL TASTE»
6.5 Switching on the appliance
Before switching on, always make sure
that there is water in the water tank
and top up if necessary. The appliance
needs water for the automatic rinsing
processes every time it is switched on
or off.
0 Switch on the appliance with the "On/
Off" button (Figure 11).
3
The appliance gets itself ready straight
after switching on. The noises occuring
at this time are completely normal.
3
During the heating up stage (approx.
120 seconds) the display shows
«HEATING UP...» on the top line
and on the bottom line a progress bar
as a percentage
«
 40%»
which shows the heating up progress.
When the appliance has finished heat-
ing up it displays:
«RINSING...» on the top line of the
display and in the bottom line a
progress bar with a percentage
«
 40%» and
does an automatic rinsing process (A
little hot water comes out of the cof-
fee dispenser and is caught in the drip
tray).
The appliance is now ready to be used.
The display appears, which depends on
the coffee mode last selected.
6.6 Switching off the appliance
0 Switch off the appliance using the
"On/Off" button (Figure 11).
The appliance does a rinsing procedure
(display shows
«RINSING...
PLEASE WAIT...») and switches
itself off.
3
If you are not using the appliance for a
long time, in addition to switching off
with the "On/Off" button, you should
also switch off the main switch at the
back of the appliance (Figure 9).
6.7 Setting the water hardness
After installing for the first time or
when using a different water quality
you should set the appliance to the
water hardness level that corresponds
with yourlocal water hardness. Use the
enclosed test strip to determine the
hardness level or ask your water
company for the water hardness.
822_949_354 ECG6600-East_Elux.book Seite 119 Freitag, 1. Februar 2008 11:36 23
