Setup
3A6283H 25
Connect Power Source
NOTE: Required voltage and amperage is noted on the
control panel label. See Power Cord Guidelines tables
below.
Use the intended entry locations shown in Junction
Box, page 17.
1. Turn the main power switch (MP) off.
2. Open the junction box door.
3. Non-Hazardous Locations only: Route the power
cord through the strain relief (ZH) into the electrical
enclosure (ZC).
Hazardous Locations only: Follow local codes
and regulations for routing the power through the
main power entry point (ZS).
NOTE: The machine is provided with jumpers in the 380
Vac 3-Phase Wye position.
NOTE: Terminal jumpers are not used for 480V.
4. Connect the ground wire to the ground terminal (G).
5. Connect the power cord to the disconnect as shown
in XPs-hf Wiring Diagram, page 26. Gently pull on
all connections to verify that they are properly
secured.
6. Non-Hazardous Locations only: Tighten the strain
relief (ZH).
Hazardous Locations: Follow local codes and
regulations for sealing the power cable entering into
the enclosure.
7. Install the supplied terminal jumpers in the positions
shown in the XPs-hf Wiring Diagram, page 26.
8. Verify that all items are connected properly as
shown in the XPs-hf Wiring Diagram, page 26,
then close the electrical enclosure (ZC) door.
Power Cord Guidelines
Use the guidelines listed in the table below to determine the power cord needed for your specific system.
To help prevent injury from electric shock, turn off and
disconnect power at the main switch before
connecting any cables and before servicing
equipment. All electrical work must be done by a
qualified electrician and comply with local codes and
regulations.
Models with 240 Volt Viscon HF Fluid Heater
Junction Box
Full Load Peak Amperes (A)
xxxx01 xxxx11 xxxx02 xxxx12 xxxx03 xxxx13
240 V, 1 Phase 87 87 71 71 84 84
240 V, 3 Phase 76 76 65 65 73 73
380 V, 3 Phase 48 48 48 48 48 48
480 V
Models with 480 Volt Viscon HF Fluid Heater
Junction Box
Full Load Peak Amperes (A)
xxxx21 xxxx31 xxxx22 xxxx32 xxxx23 xxxx33
240 V, 1 Phase
240 V, 3 Phase
380 V, 3 Phase
480 V 28 28 26 26 27 27
