Parts
3A6283H 79
XP-hf Pump Assembly Parts List
Ref. Part Description Qty.
901 273087 PLATE, XP-hf, motor
1
902 273086 ROD, tie, 4 in. long, 1 in. dia
3
903 273088 MOTOR, air, 13 in.
1
904 273085 ROD, adapter
1
905 262468 ROD, tie, 14.25 long, w/shoulder
4
906 262469 ROD, tie, 14.25 long, 1.25 dia
2
907 129383 NUT, 5/8-11, flanged, sst
3
908 101712 NUT, lock
6
909 184096 NUT, yoke
1
910 17R501 BRACKET, ratio indicator
1
911 273090 YOKE, pump assembly
1
912 273091 ROD, adapter, Xtreme, hf
2
913 262472 SLEEVE, bearing
2
916 123976 RING, snap, external
2
921 273089 BRACKET, XP-hf, finger guard
1
921a 16P338 SCREW, mach, serrated hex hd
2
921b 17N312 PLATE, XP-hf, finger guard
1
922 273092 COVER, pump
2
922a 121803 SCREW, cap, button head
8
922b 124172 WASHER, retaining, nylon, 10-32
8
922c 124665 NUT, captive, 10-32
4
922d 15T468 LABEL, warning
2
930 124078 CLAMP, spring, constant-tension
2
931 15H108 LABEL, safety, warning, pinch
1
932 111192 SCREW, cap flange hd
2
934 184130 BRACKET, ratio indicator
1
935 16E882 STRAP, lowers
2
940 244525 WIRE, grounding assembly
1
Replacement safety labels, tags, and cards are
available at no cost.
Ref. Part Description Qty.
Ref. Description 57710x 57720x 57730x 57740x 57810x 57820x 57830x 57840x Qty.
4 PUMP, assembly 572100 572200 572300 572400 573100 573200 573300 573400 1
917 PUMP, lower, A L14AC0 L18AC0 L22XC0 L22XC0 L22AC0 L29AC0 L29AC0 L29AC0 1
918 PUMP, lower, B L14AC0 L090C0 L072C0 L054C0 L22AC0 L14AC0 L097C0 L072C0 1
919 COUPLING, A 244819 244819 244819 244819 244819 244819 244819 244819 1
920 COUPLING, B 244819 247167 247167 247167 244819 244819 247167 247167 1
929 LABEL, XP-hf 17N281 17N281 17N281 17N281 17N282 17N282 17N282 17N282 4
56 VALVE, safety 113498 114055 113498 114055 113498 113498 114055 16M190 1
