Graco XP70s-hf 577222 [84/86] Double wall hopper
![Graco XP70s-hf 577222 [84/86] Double wall hopper](/views2/1906144/page84/bg54.png)
Technical Specifications
84 3A6283H
XXXX31 1475 lb 700 kg
XXXX32 1425 lb 646 kg
XXXX33 1450 lb 658 kg
Sound Data
Sound Power measured at 70 psi
(0.48 MPa, 4.8 bar), 20 cpm, per ISO-9614-2
Greater than 96 dBA
Sound Pressure tested at
3.28 ft (1 m) from equipment
Greater than 86.8 dBA
Proportioner
U.S. Metric
Input
Maximum air input 100 psi
6.7 bar, 0.67 MPa
Air inlet size 1 in. npsm
Fluid pump inlets 1-1/4 npt (m)
Output
Fluid gauge manifold 1/2 in. npt(f)
Fluid mix manifold inlets (ball valves) 1/2 in. npsm
Mix manifold material outlet 1/2 npt(f)
Sound Data
See XL 10k Air Motor manual for sound data.
Air consumption per 1 gpm (3.78 lpm) of flow
XPs70-hf 75 cfm at 100 psi
2.12 m3/min at 6.7 bar, 0.67 MPa
XPs50-hf 60 cfm at 100 psi
1.7 m3/min at 6.7 bar, 0.67 MPa
Double Wall Hopper
U.S. Metric
Temperature (set point) 110 °F 43 °C
Spray material capacity 25 gallons
94.6 liters
Heating fluid capacity 12 gallons
53 liters
Feed Pump
U.S. Metric
Input
Maximum air input 100 psi
6.7 bar, 0.67 MPa
Air inlet size 3/8 in. npt(f)
Output
Maximum working pressure 500 psi
34.4 bar, 3.4 MPa
Fluid outlet size 3/4 in. npt(f)
Flow at maximum pump speed: (66 cycles/min) 2.5 gallons per minute 9.5 liters per minute
Air consumption per 1 gpm (3.78 lpm) of flow
8 cfm at 100 psi
0.23 m3/min at 6.7 bar, 0.67 MPa
Sound Data
See Monark Air Motor manual for sound data.
