Graco XP70s-hf 577222 [67/86] Non heated hose packages parts list
![Graco XP70s-hf 577222 [67/86] Non heated hose packages parts list](/views2/1906144/page67/bg43.png)
Parts
3A6283H 67
Non-Heated Hose Packages Parts List
Ref. Part Description
Qty.
240 V 480 V
Ordinary
Locations
Hazardous
Locations
Ordinary
Locations
Hazardous
Locations
XXXX02 XXXX12 XXXX22 XXXX32
10
17N599 HARNESS, B heater, non-hazardous 1 1
11
17N598 HARNESS, A heater, non-hazardous 1 1
14
116171 BUSHING, strain relief 1 1
27
26C580 JUNCTION BOX, 240V, non-hazardous 1
26C581 JUNCTION BOX, 240V, hazardous 1
26C582 JUNCTION BOX, 480V, non-hazardous 1
26C583 JUNCTION BOX, 480V, hazardous 1
28
25C961 HEATER, hf, 240V, non-hazardous 2
25C962 HEATER, hf, 240V, hazardous 2
26C471 HEATER, hf, 480V, non-hazardous 2
26C476 HEATER, hf, 480V, hazardous 2
33
166590 FITTING, bushing adapter 2 2
34
185065 ADAPTER, cable 4 4
38
110963 SCREW, cap, flanged head 4 4
C19075 SCREW, cap, hex head 4 4
63
111841 WASHER 4 4
203
26C482 HOPPER, heated, 240V 2 2
26C479 HOPPER, heated, 480V 22
204
17X398 HARNESS, hopper 2 2
233
121603 GRIP, cord 2 2
240
122032 NUT, wire (not shown) 8 8
