Repair
3A6283H 59
Material Recirculation Manifold Replacement Guide
Material Recirculation Manifold Replacement Table
Circulation
Manifold (35)
Part
Relief
Valve (302)
Part
Valve Sleeve
Color
Target Opening
Pressure
psi (MPa, bar) Use with:
262783 262809 Gold 7100 (49, 490) All XPs50-hf models
262806 262520 Silver 9250 (64, 638) All XPs70-hf models
Colored Valve Sleeve
ti19168a
ti19169a
