Parts
3A6283H 65
Water Jacketed Heated Hose Packages Parts List
Ref. Part Description
Qty.
240V 480V
Ordinary
Locations
Hazardous
Locations
Ordinary
Locations
Hazardous
Locations
XXXX01 XXXX11 XXXX21 XXXX31
10
17N599 HARNESS, B heater, non-hazardous 1 1
11
17N598 HARNESS, A heater, non-hazardous 1
1
14
116171 BUSHING, strain relief 2
2
27
26C580 JUNCTION BOX, 240V, non-hazardous 1
26C581 JUNCTION BOX, 240V, hazardous 1
26C582 JUNCTION BOX, 480V, non-hazardous 1
26C583 JUNCTION BOX, 480V, hazardous 1
28
25C961 HEATER, hf, 240V, non-hazardous 2
25C962 HEATER, hf, 240V, hazardous 2
26C471 HEATER, hf, 480V, non-hazardous 2
26C476 HEATER, hf, 480V, hazardous 2
33
166590 FITTING, bushing adapter 3 3
34
185065 ADAPTER, cable 5 5
38
110963 SCREW, cap, flanged head 4 4
C19075 SCREW, cap, hex head 4 4
63
111841 WASHER 4 4
203
26C482 HOPPER, heated, 240V 2 2
26C479 HOPPER, heated, 480V 22
204
17X398 HARNESS, hopper 2 2
231
16P608 CLAMP, mounting, top, heater 2 2 2 2
232
117535 SCREW, cap, socket head 4 4 4 4
233
121603 GRIP, cord 2
2
234
126896 FITTING, elbow 1 1 1 1
235
126898 FITTING, elbow 1 1 1 1
236
126900 FITTING, elbow 1 1 1 1
237
17D306 FITTING, coupler 1 1 1 1
238
113796 SCREW, flanged 8 8 8 8
239
17P759 TUBE 1 1 1 1
240
122032 NUT, wire (not shown) 10
10
241
273093 PUMP, heated hose 1 1 1 1
242
17X552 BRACKET, recirc pump 1 1 1 1
243
245869 HEATER, hose, 240V, non-hazardous 1
245863 HEATER, hose 240V, hazardous 1
245870 HEATER, hose 480V, non-hazardous 1
245864 HEATER, hose, 480V, hazardous 1
244
17N600 HARNESS, WJ, hose heat 1
1
245
17P594 FITTING, house coupler 1 1 1 1
246
17S051 FITTING, hose nipple 1 1 1 1
247
24Z934 KIT, heater block, remote manifold 1 1 1 1
248
113974 SCREW, mach, slotted 1 1 1 1
