Graco XP70s-hf 577222 [70/86] Electric heated hose packages parts list
![Graco XP70s-hf 577222 [70/86] Electric heated hose packages parts list](/views2/1906144/page70/bg46.png)
Parts
70 3A6283H
Electric Heated Hose Packages Parts List
Ref. Part Description
Qty.
240 V 480 V
Ordinary
Locations
Hazardous
Locations
Ordinary
Locations
Hazardous
Locations
XXXX03 XXXX13 XXXX23 XXXX33
10
17N599 HARNESS, B heater, non-hazardous 1 1
11
17N598 HARNESS, A heater, non-hazardous 1 1
14
116171 BUSHING, strain relief 1 1
27
26C899 JUNCTION BOX, 240V, non-hazardous 1
26C905 JUNCTION BOX, 240V, hazardous 1
26C904 JUNCTION BOX, 480V, non-hazardous 1
26C906 JUNCTION BOX, 480V, hazardous 1
28
25C961 HEATER, hf, 240V, non-hazardous 2
25C962 HEATER, hf, 240V, hazardous 2
26C471 HEATER, hf, 480V, non-hazardous 2
26C476 HEATER, hf, 480V, hazardous 2
33
166590 FITTING, bushing adapter 2 2
34
185065 ADAPTER, cable 5 4
38
110963 SCREW, cap, flanged head 4 4
C19075 SCREW, cap, hex head 4 8
63
111841 WASHER 4 4
64
18C158 SPLICE BOX 1
18B948 SPLICE BOX, explosion-proof 2 2
65
115942 NUT 3
112958 NUT 44
66
18C151 COVER, splice box 1
19B335 BRACKET, splice box 1
67
19Y807 BUSHING, strain relief 1 1
68
19B130 CORD, cable 1 1
69
128986 CONNECTOR, splice 2
70
26C791 TRANSFORMER 1
19B356 TRANSFORMER, 5kV, hazardous 1
71
19B359 BRACKET, transformer 1
72
132001 BOLT, flange, serrated 4
73
112395 SCREW, cap 44
74
112958 NUT, hex flanged 44
75
25T264 KIT, fittings (not shown) 1 1 1 1
203
26C482 HOPPER, heated, 240V 2 2
26C479 HOPPER, heated, 480V 22
204
17X398 HARNESS, hopper 2 2
233
121603 GRIP, cord 2 2
240
122032 NUT, wire (not shown) 8 8
