Graco XP70s-hf 577222 [85/86] End of product life
![Graco XP70s-hf 577222 [85/86] End of product life](/views2/1906144/page85/bg55.png)
Technical Specifications
3A6283H 85
Recycling and Disposal
End of Product Life
At the end of a product’s useful life, recycle it in a
responsible manner.
California Proposition 65
Xtreme Duty Agitator
U.S. Metric
Input
Maximum air input 100 psi
6.7 bar, 0.67 MPa
Air inlet size 3/8 in. npsm
Air Consumption
30 rpm at 20 psi (1.4 bar, 0.14 MPa) 7 cfm
0.198 m3/min
60 rpm at 80 psi (5.5 bar, 0.55 MPa) 30 cfm
0.850 m3/min
Maximum free speed at 100 psi (6.7 bar, 0.67 MPa) 60 cfm
1.70 m3/min
Speed
Maximum shaft speed 60 rpm
Gear ratio 20:1
Torque:
Stall torque at maximum pressure 1120 in-lb 127 N•m
Sound Data
See XD Agitator manual for sound data.
Solvent Pump
U.S. Metric
Input
Air pressure 10 - 100 psi
0.67 MPa - 6.7 bar
Air inlet size 1/2 in. npt(f)
Output
Maximum working pressure 4500 psi
3.1 MPa, 31 bar
Fluid outlet size 3/8 in. npt
Flow at maximum pump speed (60 cpm) 0.9 gpm 3.0 lpm
Air Consumption
Per 0.5 gpm (1.89 lpm) of flow 20 cfm @70 psi
0.57 m^3/min at
0.48 MPa, 4.83 bar
Sound Data
See your Merkur air motor manual.
CALIFORNIA RESIDENTS
WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov.
