Technical Specifications
3A6283H 83
Technical Specifications
XPs-hf System
U.S. Metric
Output
Maximum Fluid Working Pressure See Models section beginning on page 10.
Combined Fluid Output (cc/cycle) See Models section beginning on page 10.
Pressure Ratio See Models section beginning on page 10.
Fluid Flow at 20 cpm See Models section beginning on page 10.
Maximum Storage Time 5 years (To maintain original performance, replace soft
seals after 5 years of inactivity)
Air Specifications
Required Air Flow 185 cfm (minimum)
5.23 m3/min (minimum)
Supply Pressure 30-100 psi
2.0-6.7 bar, 0.2-0.67 MPa
Inlet Size 1 in. npsm 2.54 cm npsm
Inlet Filtration 40-micron filter/separator included
Electrical Specifications
See XPs-hf Wiring Diagram, page 26
Filtration
Feed Pump Outlet/Y-Strainer 20 mesh
XP Pump Outlets 30 mesh
XTR Spray Gun 60 mesh
Viscosity
Gravity Feed 200 - 20,000 cps (pourable)
Pressure Feed Any viscosity that will not require feed pressure more
than 15% of outlet pressure
Temperature
Operating 40-130 °F 4-54 °C
Storage 30-160 °F 1-71 °C
Maximum Fluid Temperature 160 °F 71 °C
Wetted Materials
Housings and Manifold Carbon steel with electroless nickel plating
Displacement Pump Packings Carbon filled PTFE, proprietary UHMWPE
Solvent Pump Stainless steel, PTFE, UHMWPE,
aluminum, tungsten carbide
Hoses Plated carbon steel, Nylon
Feed Pump Plated carbon steel, PTFE
Agitator Stainless steel
Hopper Stainless steel, brass, nickel plating
Miscellaneous Parts Carbide, acetal, solvent resistant plastics
Dry Weight (does not include stand alone transformer)
XXXX01 1350 lb 612 kg
XXXX02 1300 lb 590 kg
XXXX03 1325 lb 596 kg
XXXX11 1350 lb 612 kg
XXXX12 1300 lb 590 kg
XXXX13 1475 lb 700 kg
XXXX21 1475 lb 700 kg
XXXX22 1425 lb 646 kg
XXXX23 1450 lb 658 kg
