Setup
28 3A6283H
4. Loosen the three nuts below the motor tie rods (P). 5. Slide the tie rods (P) and motor (E) until the
indicator lines are aligned with your ratio.
6. Tighten the three nuts.
7. Install the pump guards.
Air Motor shown
WLD
99
1876
(
3
NOTICE
Do not hit the tie rods (P) with a hammer. Damage
to the air motor base may result.
