d) Block the inlet duct (5) with a rag to prevent
any dirt from entering.
e) Carry out maintenance on the filtering ele-
ment as described below for each type.
f) Clean inside the filter housing (4) to get rid of
any dust, debris or dirt, taking care not to
push anything into the induction pipe (5).
g) Put the filtering element (3 - 3a) back in place
and close the cover (1).
• Sponge filtering element (3)
Keep the filtering element clean and soaked in
oil. Replace it if it is disintegrating, cut or broken.
Do not use compressed air
to clean the filtering element.
– Clean the sponge filtering element with water
and detergent and dry it with a clean cloth.
– Soak the filtering element in 2 tablespoonfuls
of clean engine oil and wring it well to distrib-
ute the oil evenly.
– Remove any excess oil with a clean cloth.
If you need to replace the filtering element, oil
the new filter as described above.
• Cartridge filtering element (3a)
– Blow compressed air from the inside to remo-
ve dust and debris.
SPARK PLUG SERVICE
a) Remove the spark plug (1) using a spark plug
socket wrench (2).
b) Clean the electrodes (3) with a metal brush
and remove any carbonaceous build-up.
c) Using a thickness gauge (4), check for the
right gap (0.6 - 0.8 mm) between the elec-
trodes.
d) Install the spark plug (1) and tighten with a
socket wrench (2).
Replace the spark plug if the electrodes are
burnt or if the porcelain is broken or damaged.
Fire hazard! Do not check
the ignition system with spark plug remov-
ed.
Use only spark plugs of the
recommended type (see 8.1).
IMPORTANT
!
WARNING!
6.6
IMPORTANT
ADJUSTMENT OF THE
ACCELERATOR CABLE
If the engine does not reach its maximum rpm
with the throttle control in «FAST» position, this
is likely due to an out-of-phase connection
between the accelerator lever and the governor
lever.
To restore the correct phase:
a) Stop the engine, remove the spark plug cap
and wait until the engine has cooled.
b) Loosen the screw (1) of the clamp (2) so that
the cable casing (3) is free to move.
c) Move the throttle control to «CHOKE».
d) Move governor control lever (4) forward as far
as possible and, by keeping it in this position,
lock the casing (3) full tightening the screw (1)
of the clamp (2).
6.7
7
EN
