GENERAL INFORMATION 1-9
General Specific ations
Items VN1600-A1 ∼
Dimensions:
Overall length 2 505 mm (98.62 in.)
Overall width 1 040 mm (40.9 in.), (AU) 990 mm (39 in.)
Overall height 1 130 mm (44.5 in.)
Wheelbase
1 680 mm (66.1 in.)
Road clearance 130 mm (5.12 in.)
Seat height 680 mm (26.8 in.)
Dry mass 306 kg (675 lb), (AU) 307 kg (677 lb)
Curb mass:
Front
156 kg (345 lb)
Rear 181 kg (399 lb), (AU) 182 kg (401 lb)
Fuel tank capacity
20 L (5.3 US gal)
Fuel Unleaded and high-octane gasoline
(see VN1600-A1 ∼ Owner’s Manual)
Performance:
Minimum turning radius
3.5 m (11.5 f t)
Engine:
Type
4-stroke, SOHC, V2-cylinder
Cooling system Liquid-cooled
Bore and stroke
102 × 95 mm (4.02 × 3.74 in.)
Displacement 1 552 mL (94.70 cu in.)
Compression ratio
9.0 : 1
Maximum horsepower 49 kW (67 PS) @ 4 700 r/min (rpm), (CA) (CAL) (US) –
Maximum torque
127 N·m (12.95 kgf·m, 93.7 ft·lb) @ 2 700 r/min (rpm),
(CA) (CAL) (US) –
Carburetion system DFI (Digital Fuel Injection) System
Starting system Electric starter
Ignition system
Battery and coil (transistorized)
Timing advance Electronically advanced (digital)
Ignition timing
From 0° BTDC @ 950 r/min (rpm) ∼ 25° BTDC @ 4 500
r/min (rpm)
Spark plugs NGK DPR6EA-9 or ND X20EPR-U9
Cylinder numbering m ethod Front to Rear, 1-2
Firing order 1-2
Valve timing:
Inlet Open 22° BTDC
Close 66° ABDC
Duration 268°
Exhaust Open 66° BBDC
Close 26° ATDC
Duration 272°
Lubrication system Forced lubrication (wet sump)
Engine oil: Type API SE, SF or SG class
API SH or SJ class wi th JASO MA
Viscosity SAE10W-40
Capacity 3.5 L (3.7US qt, when engine is completely disassembled
and dry)
