1-10 GENERAL INFORMATION
General Specifications
Items VN1600-A1 ∼
Drive Train:
Primary reduction system:
Type Gear
Reduction ratio 1.517 (85/56)
Clutch type Wet multi disc
Transmission:
Type 5-speed, constant mesh, return shift
Gear ratios: 1st 2.500 (40/16)
2nd 1.590 (35/22)
3rd 1.192 (31/26)
4th 0.965 (28/29)
5th 0.781 (25/32)
Final drive system:
Type Shaft
Reduction ratio 2.619 (15/21 × 33/9)
Overall drive ratio 3.105 @ Top gear
Final gear case oil:
Grade API Service Classification: GL-5 Hypoid gear oil
Viscosity SAE90 (above 5°C), SA E80 (below 5°C)
Capacity 200 m L (6.76 US oz)
Frame:
Type Tubular, double cradle
Caster (rake angel) 32°
Trail 168 mm (6.61 in.)
Front tire: Type Tubeless
Size 130/90 - 16 M/C 67H
Rear tire: Type Tubeless
Size 170/70B16 M/C 75H
Front suspension: Type Telescopic fork
Wheel travel 150 mm (5.91 in.)
Rear suspension: Type Sw ingarm
Wheel travel 95 mm (3.74 in.)
Brake Type: Front Dual disc
Rear Single disc
Electrical Equipment:
Battery Capacity 12 V 18 Ah
Headlight: Type Semi-sealed beam
Bulb 12 V 60/55 W (quartz-halogen)
Tail/brake light 12 V 5/21 W
Alternator: Type Three-phase AC, twin rotor
Rated output 42A × 14 V @ 6 000 r/min (rpm)
Specifications are subject to change without notice, and may not apply to every country.
AU: Australia
CAL: California
CA: Canada
US: United States of America
