English
6
SPECIFICATIONS
POWER TOOL
STANDARD ACCESSORIES
1 Plus driver bit (No. 2 × 50L)............................... 1
2 Battery (EBM315)...................................................... 1
3 Charger
(UC3SFL) ............................................................
1
4 Plastic case ................................................................ 1
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
1. Battery (EBM315)
Optional accessories are subject to change without notice.
No-load speed (Low/High) 200 / 600 min
–1
Drilling
Metal Steel: 2 mm,
(Thickness 1.0 mm) Aluminum: 2 mm
Capacity Machine screw 5 mm
Driving
Wood screw
3.5 mm (diameter) × 20 mm (length)
(Requires a pilot hole)
Rechargeable battery EBM315: Li-ion 3.6 V (1.5 Ah 1 cell)
Weight 0.4 kg
APPLICATIONS
䡬 Driving and removing of machine screws, wood
screws, tapping screws, etc.
䡬 Drilling of various metals
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the handle tightly and push the battery release
buttons (2 pcs.) to remove the battery (see Figs. 1 and
2).
CAUTION:
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 2).
CHARGING
Before using the driver drill, charge the battery as follows.
1. Connect the charger’s power cord to a receptacle.
2. Insert the battery into the charger.
Firmly insert the battery into the charger till it contacts
the bottom of the charger and checking the polarities
as shown in Fig. 3.
CHARGER
Model UC3SFL
Charging voltage 3.6 V
Weight 0.3 kg
PRECAUTIONS FOR CORDLESS DRIVER
DRILL
1. Always charge the battery at a temperature of 10 –
40°C. A temperature of less than 10°C will result in
over charging which is dangerous. The battery
cannot be charged at a temperature higher than
40°C.
The most suitable temperature for charging is that
of 20 – 25°C.
2. When one charging is completed, leave the charger
for about 15 minutes before the next charging of
battery.
Do not charge more than two batteries
consecutively.
3. Do not allow foreign matter to enter the hole for
connecting the rechargeable battery.
4. Never disassemble the rechargeable battery and
charger.
5. Never short-circuit the rechargeable battery. Short-
circuiting the battery will cause a great electric
current and overheat. It results in burn or damage
to the battery.
6. Do not dispose of the battery in fire.
If the battery is burnt, it may explode.
7. When drilling in wall, floor or ceiling, check for
buried electric power cord, etc.
8. Bring the battery to the shop from which it was
purchased as soon as the post-charging battery life
becomes too short for practical use. Do not dispose
of the exhausted battery.
9. Using an exhausted battery will damage the charger.
10. Do not insert object into the air ventilation slots of
the charger.
Inserting metal objects or inflammables into the
charger air ventilation slots will result in electrical
shock hazard or damaged charger.
