Fine-Tuning Open Loop Vector Control
Table 6.2 Parameters for Fine-Tuning Performance in OLV
Problem Parameter No. Corrective Action Default
Suggested
Setting
• Poor motor torque
and speed response
•
Motor hunting and
oscillation at speeds
between 10
and 40 Hz
Speed Feedback
Detection Control (AFR)
Gain
(n2-01)
• Gradually reduce the setting in 0.05 increments if motor torque
and speed response are too slow.
• Gradually increase the setting in 0.05 increments if motor hunting
and oscillation occur.
1.00 0.50 to 2.00
• Poor motor torque
and speed response
• Motor hunting and
oscillation at speeds
between 10 and 40 Hz
Speed Feedback
Detection Control (AFR)
Time Constant 1
(n2-02)
• Gradually reduce the setting in 10 ms increments and check the
performance to improve motor torque speed response.
• Gradually increase the setting by 50 ms increments and check the
performance if motor hunting and oscillation occur as a result of
load inertia.
Note: When changing n2-02, set C4-02 (Torque
Compensation Primary Delay Time) accordingly.
50 ms 50 to 2000 ms
• Poor motor torque
and speed response
• Motor hunting and
oscillation
Torque Compensation
Primary Delay Time
(C4-02)
• Gradually reduce the setting in 2 ms increments and check the
performance to improve motor torque speed response.
• Gradually increase the setting in 10 ms increments if motor
hunting and oscillation occur.
Note:
Ensure that C4-02 ≤ C4-06. When making
adjustments to C4-02, increase the Speed Feedback
Detection Control (AFR) Time Constant 1 (n2-02)
proportionally.
20 ms 20 to 100 ms
Poor speed response
and stability
Slip Compensation
Primary Delay Time
(C3-02)
• Gradually reduce the setting in 10 ms increments if response is
slow.
• Gradually increase the setting in 10 ms increments if speed is
unstable.
200 ms 100 to 500 ms
Poor speed precision
Slip Compensation Gain
(C3-01)
•
Gradually increase the setting in 0.1 ms increments if speed is too
slow.
• Gradually reduce the setting in 0.1 ms increments if speed is too
fast.
1.0 0.5 to 1.5
Poor speed precision
during regenerative
operation
Slip Compensation
Selection during
Regeneration (C3-04)
Enable slip compensation during regeneration by setting parameter
C3-04 = 1.
0 1
• Motor noise
• Motor hunting and
oscillation occur at
speeds below 10 Hz
Carrier Frequency
Selection (C6-02)
• Increase the carrier frequency if there is too much motor noise.
• Reduce the carrier frequency if motor hunting and oscillation
occur at low speeds.
Note: The default setting for the carrier frequency depends
on the drive model selection (o2-04) and drive duty
mode selection (C6-01).
1 (4 kHz) 1 to max. setting
• Poor motor torque at
low speeds
• Poor speed response
• Motor instability at
start
Middle Output
Frequency Voltage
(E1-08)
Minimum Output
Frequency Voltage
(E1-10)
• Increase the setting if motor torque and speed response are too
slow.
• Reduce the setting if the motor exhibits excessive instability at
start-up.
Note: When working with a relatively light load, increasing
this value too much can cause overtorque.
Depends on
o2-04,
Drive
Model
Selection
Default setting
±2 V
When using OLV, leave the torque compensation gain (C4-01) at its default setting of 1.00.
6.2 Motor Performance Fine-Tuning
YASKAWA ELECTRIC SIEP C710636 04C U1000 Industrial MATRIX Drive Technical Manual
325
6
Troubleshooting
