User’s Manual of WGSW-24040 / WGSW-24040R

SGSW-24040 / SGSW-24040R

219

• Total Power Reserved

Shows how much the total power be reserved for all PDs.

• PoE Temperature Unit 1

Display the current operating temperature of PoE chip unit 1.

The unit 1 is in charge of PoE Port-1~Port-12

• PoE Temperature Unit 2

Display the current operating temperature of PoE chip unit 2.

The unit 1 is in charge of PoE Port-13~Port-24

• Local Port

This is the logical port number for this row.

•

Display the class of the PD attached to the port, as established by the classification

process.

Class 0 is the default for PDs. The PD is classified based on power. The

classification of the PD is the maximum power that the PD will draw across all input

voltages and operational modes. A PD shall return Class 0 to 3 in accordance with

the maximum power draw as specified by Table 4-17-1.

• Power Reserved

The Power Reserved shows how much the power the PD has reserved.

• Power Used

The Power Used shows how much power the PD currently is using.

• Current Used

The Power Used shows how much current the PD currently is using.

• Priority

The Priority shows the port's priority configured by the user.

• Port Status

The Port Status shows the port's status.

• Total

Show the total watts usage of all PDs.
