User’s Manual of WGSW-24040 / WGSW-24040R

SGSW-24040 / SGSW-24040R

− Private VLAN Edge (PVE)

■ Support Spanning Tree Protocol

− STP, IEEE 802.1d (Spanning Tree Protocol)

− RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol)

■ Support Link Aggregation

− 802.3ad Link Aggregation Control Protocol (LACP)

− Cisco ether-channel (Static Trunk)

− Maximum 12 trunk groups, up to 16 ports per trunk group

− Up to 16Gbps bandwidth(Duplex Mode)

■ Provide Port Mirror (many-to-1)

■ Port Mirroring to monitor the incoming or outgoing traffic on a particular port

¾ Quality of Service

■ 4 priority queues on all switch ports.

■ Supports for strict priority and weighted round robin (WRR) CoS policies

■ Ingress Shaper and Egress Rate Limit per port bandwidth control

■ Traffic-policing policies on the switch port

¾ Multicast

■ Supports IGMP Snooping v1, v2 and v3

■ Querier mode support

¾ Security

■ IEEE 802.1x Port-Based / MAC-Based network access authentication

■ IP-Based Access Control List (ACL)

■ MAC-Based Access Control List

¾ Management

■ WEB-based, Telnet, Console Command Line management

■ Accesses through SNMPv1, v2c and v3 security set and get requests.

■ Built-in Trivial File Transfer Protocol (TFTP) client

■ BOOTP and DHCP for IP address assignment

■ Firmware upload/download via HTTP / TFTP

■ SNTP (Simple Network Time Protocol)

■ LLDP Protocol

¾ Stacking

■ Hardware stack up to 16 units and 384 ports

■ Stacking architecture supports Chain and Ring mode
