1. INTRODUTION

The PLANET Layer 2 Managed Gigabit Switch series – WGSW standalone, SGSW Stackable, SGSW PoE and SGSW Fiber

switch are all multiple ports Gigabit Ethernet Switched with SFP fiber optical connective ability and robust layer 2 features; the

description of these models as below:

WGSW-24040 :

24-Port 10/100/1000Base-T with 4 Shared SFP Managed Gigabit Switch

WGSW-24040R :

24-Port 10/100/1000Base-T with 4 Shared SFP Managed Gigabit Switch / Redundant Power

SGSW-24040 :

24-Port 10/100/1000Base-T with 4 Shared SFP Managed Stackable Switch

SGSW-24040R :

24-Port 10/100/1000Base-T with 4 Shared SFP Managed Stackable Switch / Redundant Power

SGSW-24040P

24-Port 10/100/1000Base-T PoE Managed Stackable Switch / 220W

SGSW-24040P4

24-Port 10/100/1000Base-T PoE Managed Stackable Switch / 380W

SGSW-24240

24-Port 100/1000Base-X with 8 Shared TP Managed Stackable Switch

SGSW-24240R

24-Port 100/1000Base-X with 8 Shared TP Managed Stackable Switch / Redundant Power

Terms of “ Managed Switch” means the Switches mentioned titled in the cover page of this User’s manual, i.e.WGSW-24040

and SGSW-24040.

1.1 Packet Contents

Open the box of the Managed Switch and carefully unpack it. The box should contain the following items:

Check the contents of your package for following parts:

; The Managed Switch

; User’s manual CD

; Quick installation guide

; 19” Rack mount accessory kit

; Power cord

; Rubber feet

; RS-232 DB9 male Console cable

; CB-STX50 – 50cm stack cable

(SGSW Series only)

If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the carton including the

original packing material, and use them against to repack the product in case there is a need to return it to us for repair.
