User’s Manual of WGSW-24040 / WGSW-24040R
SGSW-24040 / SGSW-24040R
86
SGSW Stackable Switch
The SGSW Stackable switch supports port mirror function over stack switch.
Figure 4-4-6 Port Mirror Configuration page screenshot
The page includes the following fields:
Object Description
•
Switch to mirror to
Frames from ports that have either source or destination mirroring enabled are
mirrored to this switch.
4.4.5 SFP Module Information
You can check the physical or operational status of an SFP module via the SFP Module Information page. This page shows the
operational status, such as the transceiver type, speed, wavelength and supports distance of SFP module on a specific interface.
You can also use the hyperlink of port no. to check the statistics on an speficic interface.
