Planet SGSW-24240 [78/328] User s manual of wgsw 24040 wgsw 24040r sgsw 24040 sgsw 24040r

User’s Manual of WGSW-24040 / WGSW-24040R

SGSW-24040 / SGSW-24040R

General, if a view entry's view type is 'excluded', it should be exist another view

entry which view type is 'included' and it's OID subtree overstep the 'excluded'

view entry.

• OID Subtree

The OID defining the root of the subtree to add to the named view. The allowed

OID length is 1 to 128. The allowed string content is digital number or asterisk(*).
