Planet SGSW-24240 [190/328] User s manual of wgsw 24040 wgsw 24040r sgsw 24040 sgsw 24040r

User’s Manual of WGSW-24040 / WGSW-24040R

SGSW-24040 / SGSW-24040R

190

Make sure that the link used for managing the switch is added to the Static Mac Table before

changing to secure learning mode, otherwise the management link is lost and can only be

restored by using another non-secure port or by connecting to the switch via the serial

interface.
